Hyundai Elevator Develops Ultra-High-Speed Elevator Using Carbon Fiber Belt

May 21, 2020 (Thu.)

Hyundai Elevator Develops World’s First Carbon Fiber Belt Type 1260m/min Elevator Technology

• Applied high-tech materials with 1/6 the weight and twice the life span of conventional metal ropes
• Transit time reduced by 20% compared to Dubai Burj Khalifa, the world’s highest building

On the 21st, Hyundai Elevator (CEO Seung-Bong Song) announced its successful development of the world’s first carbon fiber belt type 1260m/min elevator technology. This is the second big achievement following the development of the world’s fastest elevator with a speed of 1080m/min in December 2009.

A total of 9 domestic companies and institutions including Hyundai Elevator, Woojin Electric, Shinsung Materials, N Plastech, DYETEC Institute, Changan Machinery, Dong Yang Manufacturing, Taekwang Industrial, and Korea Testing Laboratory (KTL) participated in this research, which was conducted over five years from 2014 with the support from the Ministry of Trade, Industry, and Energy.

The core of the 1260m/min elevator system is at the newly developed carbon fiber belt that only weighs 1/6 of the metal ropes commonly used in elevators, extending the travel distance from 600m to over 1000m while reducing electricity consumption by 30%. In particular, its high natural oscillation prevents resonance due to wind and earthquakes that may occur in high-rise buildings and enables safe operation. Moreover, the surface of the carbon fiber belt, which has excellent thermal stability and tensile strength, is coated with a polymer material to enhance its friction factor and abrasion resistance, thereby doubling its life span.

Other cutting-edge technologies have also been applied. The new elevator achieved global competitiveness with the high-speed and high-capacity hoisting system with 9-phase motors that can operate normally even if a part of the system fails, a control system equipped with a high-performance CPU and real time operating system, a streamlined capsule cage that reduces air resistance by 7% and improves comfort and stability with biomimetic technology, and a special ceramic safety device that enhances abrasion and heat resistance.

Applying this system to the highest existing building Burj Khalifa (828m) can reduce the time to reach the top floor by 20%, from 57 seconds to 46 seconds. It also makes it possible to travel to the top floor at once without having to transfer to another elevator in the middle floor due to the travel distance limit.

CEO Seung-Bong Song commented, “This will serve as a good opportunity for the development of the Korean elevator industry in that the world’s first and greatest technology has been developed through joint efforts of partners, research institutes, and Hyundai Elevator, which is the only native elevator company in Korea.”

Hyundai Elevator, which will celebrate its 36th anniversary on the 23rd, will accelerate commercialization through procedures such as establishing domestic certification standards. The company will furthermore construct the world’s highest test tower in Chungju, where the headquarters will be relocated in 2022, and install and operate the new elevator.

[Image 1] The traction machine of the world’s first carbon fiber belt type elevator with a speed of 1260m/min. The traction machine is the power source of the elevator, equivalent to a car engine.

[Image 2] Carbon fiber belt applied to the world’s first 1260m/min elevator. Its weight is reduced to one sixth of the conventional metal rope, while its life span is doubled.
